Pilkington Technical Performance Data
Suncool
| Solar Control unit configuration (6 – 16 -6) | Visible Light | Solar Energy | Solar Factor | Shading Coefficient | U – value | Colour Rendition | Project | |||||
| Outer Leaf | Inner Leaf | Total Light Transmission % | External Reflection % | Direct Transmission % | External Reflection % | Absorption % | g value | SC | Air W/m² K | Argon (90%) W/m² K | Appearance | Example |
| SUNCOOL 70/40 | CLEAR FLOAT | 70 | 10 | 38 | 28 | 34 | 0.42 | 0.49 | 1.4 | 1.1 | Neutral | |
| SUNCOOL 70/35 | CLEAR FLOAT | 69 | 11 | 16 | 34 | 31 | 0.37 | 0.43 | 1.3 | 1.0 | Neutral | |
| SUNCOOL 66/33 | CLEAR FLOAT | 65 | 11 | 16 | 32 | 33 | 0.36 | 0.41 | 1.3 | 1.0 | Neutral | |
| SUNCOOL 50/25 | CLEAR FLOAT | 49 | 18 | 34 | 33 | 43 | 0.27 | 0.31 | 1.3 | 1.0 | Neutral | |
| SUNCOOL 40/22 | CLEAR FLOAT | 39 | 20 | 19 | 35 | 46 | 0.23 | 0.26 | 1.4 | 1.1 | Neutral | |
| SUNCOOL 30/17 | CLEAR FLOAT | 30 | 25 | 15 | 37 | 48 | 0.18 | 0.21 | 1.4 | 1.1 | Neutral | |
Guardian Technical Performance Data
Sunguard
| Solar Control unit configuration (6 – 16 -6) |
Visible Light | Solar Energy | Solar Factor | Shading Coefficient | U – value | Colour Rendition | Project | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Outer Leaf | Inner Leaf | Total Light Transmission % | External Reflection % | Direct Transmission % | External Reflection % | Absorption % | g value | SC | Air W/m² K | Argon (90%) W/m² K | Appearance | Example |
| SUNGUARD SNX 60/28 | CLEAR FLOAT | 60 | 13 | 27 | 42 | 31 | 0.29 | 0.33 | 1.3 | 1.0 | Neutral | |
| SUNGUARD SN 70/37 | CLEAR FLOAT | 70 | 11 | 34 | 39 | 27 | 0.37 | 0.42 | 1.3 | 1.0 | Neutral | Twickenham Academy |
| SUNGUARD SN 62/34 | CLEAR FLOAT | 62 | 14 | 31 | 37 | 31 | 0.34 | 0.37 | 1.3 | 1.0 | Neutral | Commodity Quay Project Croydon Interchange |
| SUNGUARD SN 51/28 | CLEAR FLOAT | 51 | 12 | 25 | 37 | 38 | 0.28 | 0.32 | 1.3 | 1.0 | Neutral | York Council |
| SUNGUARD SN 40/23 | CLEAR FLOAT | 40 | 16 | 21 | 36 | 43 | 0.23 | 0.27 | 1.3 | 1.0 | Neutral | |
| SUNGUARD SN 29/18 | CLEAR FLOAT | 29 | 17 | 15 | 33 | 52 | 0.18 | 0.21 | 1.4 | 1.1 | Neutral | |
| SUNGUARD HP60/40 | CLEAR FLOAT | 60 | 25 | 37 | 35 | 27 | 0.4 | 0.46 | 1.4 | 1.1 | Neutral | |
| SUNGUARD HP50/32 | CLEAR FLOAT | 50 | 23 | 29 | 37 | 34 | 0.32 | 0.36 | 1.4 | 1.1 | Neutral | |
| SUNGUARD HP43/31 | CLEAR FLOAT | 43 | 32 | 28 | 36 | 30 | 0.31 | 0.36 | 1.5 | 1.2 | Silver | |
| SUNGUARD HP41/29 | CLEAR FLOAT | 41 | 26 | 26 | 27 | 47 | 0.29 | 0.33 | 1.4 | 1.1 | Royal Blue | |
| SUNGUARD HP40/27 | CLEAR FLOAT | 40 | 15 | 24 | 27 | 50 | 0.27 | 0.31 | 1.4 | 1.1 | Bronze | |
| SUNGUARD HP 35/26 | CLEAR FLOAT | 35 | 44 | 24 | 43 | 33 | 0.26 | 0.3 | 1.5 | 1.2 | Silver | |
Acoustic Technical Performance Data
| Frequency – Hertz | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Double insulating glass units |
125 | 250 | 500 | 1000 | 2000 | 4000 | Rw(C:Ctr) | Rw | Rw + C | Rw + Ctr |
| 4 / 16 / 4 | 24 | 18 | 26 | 40 | 45 | 39 | 30(-1:-4) | 30 | 29 | 26 |
| 4 / 16 / 6 | 24 | 21 | 29 | 43 | 43 | 45 | 34(-1:-5) | 34 | 33 | 29 |
| 4 /16 / 8 | 25 | 22 | 32 | 41 | 45 | 46 | 35(-2:-5) | 35 | 33 | 30 |
| 4 / 16 / 10 | 27 | 23 | 33 | 41 | 48 | 51 | 37(-2:-6) | 37 | 35 | 31 |
| 6 / 16 / 8.8 | 26 | 27 | 36 | 43 | 42 | 53 | 38(-1:-5) | 38 | 37 | 33 |
| 6 / 16 / 9.5 | 24 | 26 | 39 | 45 | 42 | 50 | 39(-2:-6) | 39 | 37 | 33 |
| 6 / 16 / 8.8SC | 24 | 28 | 39 | 48 | 46 | 56 | 41(-2:-6) | 41 | 39 | 35 |
| 8 / 16 / 8.8SC | 24 | 31 | 40 | 49 | 51 | 63 | 42(-2:-7) | 42 | 40 | 35 |
| 8 / 16 / 10.8SC | 24 | 31 | 41 | 46 | 46 | 59 | 42(-2:-6) | 42 | 40 | 36 |
| 8 / 16 / 12.8SC | 25 | 34 | 41 | 44 | 46 | 62 | 43(-2:-6) | 43 | 41 | 37 |
| 10 / 16 / 8.8SC | 27 | 32 | 43 | 46 | 48 | 61 | 44(-2:-6) | 44 | 42 | 38 |
| 10 / 16 / 9.5SC | 26 | 34 | 44 | 47 | 50 | 61 | 45(-3:7) | 45 | 42 | 38 |
| 10 / 16 / 10.8SC | 27 | 34 | 43 | 47 | 52 | 64 | 45(-2:-7) | 45 | 43 | 38 |
| 8.8SC / 16 / 12.8SC | 28 | 38 | 46 | 50 | 54 | 67 | 47(-2:-6) | 47 | 45 | 41 |
| 8.8SC / 16 / 13.1SC | 28 | 37 | 46 | 51 | 54 | 66 | 48(-3:-8) | 48 | 45 | 40 |
| 9.1SC / 16 / 13.1SC | 29 | 40 | 47 | 51 | 53 | 64 | 49(-3:-7) | 49 | 46 | 42 |
| 8.8SC / 16 / 16.8SC | 31 | 41 | 48 | 53 | 58 | 67 | 50(-1:-6) | 50 | 49 | 44 |
| 12.8SC / 16 / 16.8SC | 34 | 41 | 47 | 53 | 61 | 68 | 51(-1:-5) | 51 | 50 | 46 |
| Frequency – Hertz | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Triple insulating glass units |
125 | 250 | 500 | 1000 | 2000 | 4000 | Rw(C:Ctr) | Rw | Rw + C | Rw + Ctr |
| 4 / 12 / 4 / 12 / 4 | 20 | 18 | 27 | 43 | 49 | 43 | 31(-1:-5) | 31 | 30 | 26 |
| 4 / 12 / 4 / 12 / 6 | 22 | 24 | 32 | 46 | 47 | 47 | 35(-1:-5) | 35 | 34 | 30 |
| 4 / 12 / 4 / 12 / 8 | 21 | 24 | 33 | 44 | 48 | 51 | 36(-2:-6) | 36 | 34 | 30 |
| 6 / 12 / 4 / 12 / 8 | 21 | 28 | 37 | 43 | 41 | 55 | 38(-1:-5) | 38 | 37 | 33 |
| 6 / 12 / 4 / 12 / 8.8SC | 23 | 30 | 42 | 51 | 46 | 60 | 41(-2:-6) | 41 | 39 | 35 |
| 8/ 12 / 4 / 12 / 8.8SC | 24 | 31 | 40 | 48 | 47 | 60 | 42(-2:-6) | 42 | 40 | 36 |
| 8 / 12 / 5 / 12 / 8.8SC | 24 | 32 | 41 | 49 | 47 | 58 | 43(-3:-7) | 43 | 40 | 36 |
| 8.8SC / 12 / 6 / 12 / 10.8SC | 29 | 34 | 45 | 53 | 54 | 66 | 47(-2:-7) | 47 | 45 | 40 |
Low E Technical Performance Data
Energy & Energy+
| Dualtherm © SOLAR unit configuration (6 – 16 -6) |
Visible Light | Energy Factors | Solar Factor | Shading Coefficient | U – value | Colour Rendition | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Outer Leaf | Inner Leaf | Total Light Transmission % | External Reflection % | Direct Transmission % | External Reflection % | Absorption % | g value | SC | Air W/m ² K | Argon (90%) W/m ² K | Appearance |
| GREY FLOAT | LOW E | 39 | 6 | 28 | 11 | 61 | 0.36 | 0.41 | 1.4 | 1.1 | Grey |
| BRONZE FLOAT | LOW E | 43 | 7 | 30 | 12 | 58 | 0.37 | 0.43 | 1.4 | 1.1 | Bronze |
| GREEN FLOAT | LOW E | 65 | 10 | 33 | 9 | 58 | 0.4 | 0.47 | 1.4 | 1.1 | Green |
| BLUE FLOAT | LOW E | 47 | 7 | 26 | 7 | 67 | 0.33 | 0.38 | 1.4 | 1.1 | Blue |
| STOPSOL ON CLEAR | LOW E | 55 | 36 | 37 | 39 | 24 | 0.45 | 0.52 | 1.4 | 1.1 | Silver |
| STOPSOL ON GREY | LOW E | 26 | 12 | 19 | 15 | 66 | 0.26 | 0.3 | 1.4 | 1.1 | Silver Grey |
| LOW E ‘ONE’ | CLEAR FLOAT | 70 | 22 | 43 | 36 | 18 | 0.47 | 0.54 | 1.3 | 1 | Neutral |
| SUNGUARD SOLAR 67 | LOW E | 58 | 19 | 41 | 22 | 38 | 0.48 | 0.55 | 1.4 | 1.1 | Neutral |
| SUNGUARD SOLAR 32 | LOW E | 28 | 22 | 18 | 20 | 61 | 0.24 | 0.27 | 1.4 | 1.1 | Silver Grey |
| SUNGUARD SOLAR 20 | LOW E | 19 | 18 | 13 | 19 | 68 | 0.18 | 0.21 | 1.4 | 1.1 | Royal Blue |
| SUNGUARD SOLAR S20 | LOW E | 19 | 34 | 12 | 33 | 55 | 0.17 | 0.19 | 1.4 | 1.1 | Silver |
| SUNGUARD SOLAR B20 | LOW E | 19 | 17 | 11 | 20 | 68 | 0.16 | 0.18 | 1.4 | 1.1 | Bronze |
| SUNGUARD SOLAR 08 | LOW E | 8 | 43 | 6 | 35 | 59 | 0.09 | 0.11 | 1.4 | 1.1 | Silver |
Technical Performance Data
| Dualtherm © SOLAR unit configuration (6 – 16 -6) | Visible Light | Energy Factors | Solar Factor | Shading Coefficient | U – value | Colour Rendition | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Outer Leaf | Inner Leaf | Total Light Transmission % | External Reflection % | Direct Transmission % | External Reflection % | Absorption % | g value | SC | Air W/m ² K | Argon (90%) W/m ² K | Appearance |
| GREY FLOAT | LOW E | 39 | 6 | 28 | 11 | 61 | 0.36 | 0.41 | 1.4 | 1.1 | Grey |
| BRONZE FLOAT | LOW E | 43 | 7 | 30 | 12 | 58 | 0.37 | 0.43 | 1.4 | 1.1 | Bronze |
| GREEN FLOAT | LOW E | 65 | 10 | 33 | 9 | 58 | 0.4 | 0.47 | 1.4 | 1.1 | Green |
| BLUE FLOAT | LOW E | 47 | 7 | 26 | 7 | 67 | 0.33 | 0.38 | 1.4 | 1.1 | Blue |
| STOPSOL ON CLEAR | LOW E | 55 | 36 | 37 | 39 | 24 | 0.45 | 0.52 | 1.4 | 1.1 | Silver |
| STOPSOL ON GREY | LOW E | 26 | 12 | 19 | 15 | 66 | 0.26 | 0.3 | 1.4 | 1.1 | Silver Grey |
| COOL-LITE ST150 | LOW E | 45 | 19 | 30 | 20 | 45 | 0.36 | 0.42 | 1.4 | 1.1 | Blue |
| SOLAR NEUTRAL 67 | LOW E | 58 | 19 | 41 | 22 | 38 | 0.48 | 0.55 | 1.4 | 1.1 | Neutral |
| SOLAR SILVER GREY 32 | LOW E | 28 | 22 | 18 | 20 | 61 | 0.24 | 0.27 | 1.4 | 1.1 | Silver Grey |
| SOLAR ROYAL BLUE 20 | LOW E | 19 | 18 | 13 | 19 | 68 | 0.18 | 0.21 | 1.4 | 1.1 | Royal Blue |
| SOLAR SILVER 20 | LOW E | 19 | 34 | 12 | 33 | 55 | 0.17 | 0.19 | 1.4 | 1.1 | Silver |
| SOLAR BRONZE 20 | LOW E | 19 | 17 | 11 | 20 | 68 | 0.16 | 0.18 | 1.4 | 1.1 | Bronze |
| SOLAR SILVER 08 | LOW E | 8 | 43 | 6 | 35 | 59 | 0.09 | 0.11 | 1.4 | 1.1 | Silver |
Saint Gobain Technical Performance Data
Cool-Lite
| Solarcontrol unit configuration (6 – 16 -6) | Visible Light | Energy Factors | Solar Factor | Shading Coefficient | U – value | Project | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Outer Leaf | Inner Leaf | Total Light Transmission % | External Reflection % | Direct Transmission % | External Reflection % | Absorption % | g value | SC | Air W/m² K | Argon (90%) W/m² K | Example |
| COOL-LITE XTREME 60/28 | CLEAR FLOAT | 60 | 14 | 25 | 39 | 34 | 0.28 | 0.32 | 1.3 | 1.0 | |
| COOL-LITE SKN174 | CLEAR FLOAT | 68 | 11 | 37 | 28 | 32 | 0.41 | 0.47 | 1.4 | 1.1 | Hull Royal Infirmary North Durham Academy |
| COOL-LITE SKN176 | CLEAR FLOAT | 70 | 14 | 35 | 34 | 31 | 0.37 | 0.43 | 1.3 | 1.0 | Archbishop Blanch School |
| COOL-LITE SKN165 | CLEAR FLOAT | 60 | 16 | 30 | 32 | 37 | 0.33 | 0.38 | 1.3 | 1.0 | Northern Design Centre Kilner Way Retail Park |
| COOL-LITE SKN154 | CLEAR FLOAT | 50 | 18 | 24 | 34 | 41 | 0.27 | 0.31 | 1.3 | 1.0 | Ryhope Mental Hospital Trinity Shopping Centre Leeds |
| COOL-LITE SKN144 | CLEAR FLOAT | 40 | 20 | 20 | 31 | 48 | 0.23 | 0.26 | 1.4 | 1.1 | Redcar Leisure Centre |
| COOL-LITE XTREME 50/22 | CLEAR FLOAT | 50 | 17 | 20 | 38 | 42 | 0.22 | 0.25 | 1.3 | 1.1 | |
Approved Structural Systems
The following companies have awarded dualseal Ltd license to manufacture structural silicone insulating glass units incorporating individualised toggle retention channels with a nominal 23mm sealant depth*, edge deletion to suit increased seal depth and overall nominal sight line of 30mm
*Please note sealant depths may increase with environmental loadings and unit sizes, please consult dualseal technical department for further information
Altrincham Business Park
Stuart Road, Altrincham,
WA14 5GJ, United Kingdom
Longmile Road,
Dublin 12, Ireland
17 Willow Lane
Mitcham
Surrey
CR4 4NX
United Kingdom
Astmoor Industrial Estate
Runcorn, Cheshire
WA7 1QQ
United Kingdom
Steeple Road
Antrim
Northern Ireland
BT41 1AB
HBS Centre
Silkwood Park,
Wakefield
WF5 9TG
Kingston
Milton Keynes
MK10 0AL
Ceramic Spandrels
dualseal Ceramic Spandrels are an opaque coloured glass, produced by applying a uniform coating of enamel to one side of the glass. The latest range of enamels used do not contain any dangerous heavy metals.
The enamel is fired at a high temperature in order to fuse permanently with the glass surface, giving the product exceptional durability.
STANDARD CERAMIC COLOURS
BS 08B29 BRONZE TONE
BS 18B25 MID GREY
BS 00E53 BLACK
BS 14C31 WHITE
BS 14C39 CACTUS
BS 18B29 GRAPHITE
BS 18D44 BLUE
BS 18B27 GREY
BS 08B27 HARMONY BRONZE
BS 16A07 NEUTRAL
Acoustic
Sound Control
Noise pollution is a serious issue, particularly when living in an area with high levels of air traffic or busy roads. Too much noise can be damaging to health (increased stress, disrupted sleep) and can hinder academic learning and concentration.
dualseal acoustic insulating glazing can help keep noise outside so you can enjoy your living and work space in peace and quiet.
Function
Noise levels are measured in decibels (dB). A comfortable sound level is around 35dB in daytime and 30dB at night.
Acoustically, insulating glass cuts out excess sound and reduces the harmful effects of noise and is particularly effective in buildings near to high streets, urban traffic, motorways, train stations and airports.
The acoustic glass within a busy double-glazed unit comprises a special interlayer which acts as a dampening core to prevent sound frequencies from vibrating from one pane of glass to the other. This absorbs and weakens sound energy, helping to act as a barrier to noise.
Benefits
Acoustic insulation is very important to create a space where sound does not hinder concentration and does not add to the day-to-day stresses experienced at work.
You can keep the workplace at a sensible noise level so you are able to create an environment with less outside influences creating a more tranquil space.
Reduce impact noise, particularly on roof lanterns when it is raining.
Acoustic glass can be combined with many other products for multi-functional glazing, such as thermal insulation, solar control, low-maintenance and decorative glass.
Have you tried the Glass dBstation app from Saint-Gobain? Thanks to this acoustic simulator from Saint-Gobain Glass, you can easily determine the best performing glazing for your windows according to the noise pollution of your surrounding environment.
Compatibility: Requires iOS 4.0 or later.
Decorative
Ceramic Designs
Dualseal silk screen glass offers aesthetic solutions for architectural design with standard or specially commissioned designs being available. This variation in designs provide options for privacy, obscuration and solar control.
Standard patterns can be viewed using the adjacent page link view but purpose made designs are available on request and are costed individually. The designs can be applied to the whole panel or in selected areas to suit the application.
With increased ceramic coverage on the glass, screen printing helps to control heat and light transmission. The shading coefficient of clear and body tinted glass is reduced, thus allowing greater flexibility of choice and design.
Benefits
- Wide range of visual effects available
- No discolouration by internal condensation or deposit of volatiles
- Durable
- Toughened to BS EN 12150: BS EN 12600 Impact Classification 1(C)3 (minimum)
- Resists corrosion and chemical attack
- Easy to install with minimal maintenace
Vanceva®
Without light – colour would not exist. Therefore it is perfect that modern day trends continue to bring colour into glass. Often a path for natural daylight, today’s windows offer architects and designers a dynamic palette on which to display colour
No longer reserved for paint and wall coverings, architects and designers continue to push the envelope, developing colour design methods for every glazing application. When exploring light, form and space in the design process, glass can be the answer for all three considerations with the addition of Vanceva© colours.
New hospitals, living rooms and urban facades can showcase colour in the glazing design. Colour and light are used not only to define space, but to stimulate and even inspire those who inhabit it.
Please contact our technical department to guide you through the colour selection process and finalise your requirements.
ScreenLine Blinds
ScreenLine is a system of blinds, which are assembled and permanently sealed within the double-glazing cavity.
Once sealed in this totally dust free environment, the blinds require no cleaning, always appear new and are protected from damage unlike external blind systems. Benefits also include enhanced sun shading features and it also enhances the u-value of a sealed unit.
